by Wahugg » Thu Feb 28, 2013 9:26 pm

Hello All,

Over the past week I developed a small squeak that has turned into a metallic squeak/ vibration under load. At first it caused me no alarm as particles sometimes get stuck between the rotor and the pad and eventually fall out. However I began to get concerned when the squeak started to get louder, and when a small vibration started to appear.

Here's what I know.

-It's from the rear axle, un-discernible if its coming from the left, right, or diff.
-Only happens in forward direction
-Very loud under heavy acceleration
-Almost non existent under light acceleration
-Acceleration is smooth; no wobbles from unbalances though a vibration appears when in 3rd and 4th gear. (gets worse as the engine lugs)
-Diff has fluid
-Wheels are properly torqued down
-Is speed dependent not rev dependent
-The tires are not rubbing anywhere
-Brake and E/Brake pressure does not effect the sound at all

If anyone has any ideas that would be great!

Thanks!
-Wahugg


[Youtube]http://www.youtube.com/watch?v=XQSvgzojkFo[/Youtube]
Last edited by Wahugg on Thu Feb 28, 2013 9:34 pm, edited 2 times in total.
Wahugg
Addict

Posts: 576
Joined: Fri Oct 07, 2011 10:09 am
Name: Wahugg
Vehicle Year: Other
Vehicle: Other Vehicle
DriveTrain: AWD w/ G80

by fishsticks » Thu Feb 28, 2013 9:31 pm

Dry U-joints?
11 Silverado LTZ - 6.2L/6l80, 2/3 drop, self tuned
85 Hilux - 3RZ, dual cases, caged, 40s, chromo everything
02 TrailBlazer LTZ - 35s, lockers, balls - Gone but not forgotten - Build
User avatar
fishsticks
Moderator

Posts: 4356
Joined: Thu Apr 01, 2010 11:30 pm
Location: WA, Vancouver
Name: Donny
Vehicle Year: Other
Vehicle: Other Vehicle
DriveTrain: 4WD w/ Aftermarket Locker
Rank: Extreme Offroader

by djthumper » Thu Feb 28, 2013 9:39 pm

I am with Donny...
User avatar
djthumper
Moderator

Posts: 2702
Joined: Wed Mar 24, 2010 6:04 pm
Location: NV, Las Vegas
Name: Larry
Vehicle Year: 2006
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Offroad Rated

by boog2006 » Thu Feb 28, 2013 9:48 pm

djthumper wrote:I am with Donny...


What are y'all doing?
Better to remain silent and be thought a fool than to speak out and remove all doubt. - Abraham Lincoln
Boog2006 Build Thread
User avatar
boog2006
Addict

Posts: 688
Joined: Wed Jul 13, 2011 3:09 pm
Location: KY, Paducah
Name: Brent
Vehicle Year: 2006
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Offroad Rated

by fishsticks » Thu Feb 28, 2013 10:12 pm

boog2006 wrote:
djthumper wrote:I am with Donny...


What are y'all doing?



We're gettin the band back together...
11 Silverado LTZ - 6.2L/6l80, 2/3 drop, self tuned
85 Hilux - 3RZ, dual cases, caged, 40s, chromo everything
02 TrailBlazer LTZ - 35s, lockers, balls - Gone but not forgotten - Build
User avatar
fishsticks
Moderator

Posts: 4356
Joined: Thu Apr 01, 2010 11:30 pm
Location: WA, Vancouver
Name: Donny
Vehicle Year: Other
Vehicle: Other Vehicle
DriveTrain: 4WD w/ Aftermarket Locker
Rank: Extreme Offroader

by dvanbramer88 » Fri Mar 01, 2013 9:29 am

+1 on the U-joints. exactly what it sounds like to me.
Chevy Power!
Long live the Republic
"Violence is not always evil. The judicious use of violence and those willing to use it without hesitation is often all that stands between wolves and sheep."

Build Thread
User avatar
dvanbramer88
Lifer

Posts: 2283
Joined: Tue Jul 05, 2011 3:12 pm
Location: PA, Bristol
Name: Dave
Vehicle Year: 2002
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Trail Ready

by Wahugg » Fri Mar 01, 2013 10:32 am

Thanks guys for the input; I'll defiantly change those out tonight.

However I have a couple of questions even after doing a little research.

I understand that I have to burn out the plastic 'snap ring' that currently holds the u joints in place. However, on the auto-zone replacements, they show a metal snap ring that goes on in replacement. Is this right?

Also, Autozone shows that the front U-Joint and the Rear U Joint is the same. Is this true?

EDIT: Found out that the front and rear U joints are different
Front shaft number: 1-0445DG
Rear shaft number: 2-3011DG


Thanks again guys!

-Wahugg
Wahugg
Addict

Posts: 576
Joined: Fri Oct 07, 2011 10:09 am
Name: Wahugg
Vehicle Year: Other
Vehicle: Other Vehicle
DriveTrain: AWD w/ G80

by Conner299 » Fri Mar 01, 2013 10:46 am

I havent changed u-joints on the Blazer, but this sounds exactly the same as what I through with my s-10. Burn the plastic out, it'll ooze very noticably. Press the old one outs, press the new ones in. There will be a recess on the arms of the new u-joints, just on the insides of the driveshaft yoke. That's where the c-clips will go. All the u-joints i have ever changed, front and rear u-joints have been the same. Like I said though, Ive never done them on the TrailBlazer.
I DON'T care what my GMT360 was designed to do, I care about what it can do!
User avatar
Conner299
Addict

Posts: 706
Joined: Mon Oct 29, 2012 8:47 am
Location: KY, Louisville
Name: Ed
Vehicle Year: 2005
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Trail Ready

by Wahugg » Fri Mar 01, 2013 10:47 pm

Well guys i got the new u joint on the rear of the shaft. The old one wouldn't even move, and the needle bearings was just a pile of rust and grit. I just went out for a test drive and now there is a huge vibration.

I marked the drive shaft to the rear with a sharpie so the sides are matched up. The straps are oriented and I even kept the bolts in the right orientation. I'm really hoping its not a bent shaft. I'm gonna turn the shaft 180 degrees just to make sure.

Is there anything you guys can think if that I might be missing?

Thanks!
-Wahugg
Wahugg
Addict

Posts: 576
Joined: Fri Oct 07, 2011 10:09 am
Name: Wahugg
Vehicle Year: Other
Vehicle: Other Vehicle
DriveTrain: AWD w/ G80

by fishsticks » Fri Mar 01, 2013 11:12 pm

There are two U-joints on the shaft. :mrgreen:
11 Silverado LTZ - 6.2L/6l80, 2/3 drop, self tuned
85 Hilux - 3RZ, dual cases, caged, 40s, chromo everything
02 TrailBlazer LTZ - 35s, lockers, balls - Gone but not forgotten - Build
User avatar
fishsticks
Moderator

Posts: 4356
Joined: Thu Apr 01, 2010 11:30 pm
Location: WA, Vancouver
Name: Donny
Vehicle Year: Other
Vehicle: Other Vehicle
DriveTrain: 4WD w/ Aftermarket Locker
Rank: Extreme Offroader

by djthumper » Fri Mar 01, 2013 11:38 pm

fishsticks wrote:There are two U-joints on the shaft. :mrgreen:

ROFL! :Iagree:
User avatar
djthumper
Moderator

Posts: 2702
Joined: Wed Mar 24, 2010 6:04 pm
Location: NV, Las Vegas
Name: Larry
Vehicle Year: 2006
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Offroad Rated

by Conner299 » Fri Mar 01, 2013 11:44 pm

djthumper wrote:
fishsticks wrote:There are two U-joints on the shaft. :mrgreen:

ROFL! :Iagree:


ROFL!... :Iagree:

See.. If there was a "like" button, I wouldn't have to go through all this B.S., of making a wasteful post. Driveshaft u-joints are like shocks, or brakes... Always replace in pairs...
I DON'T care what my GMT360 was designed to do, I care about what it can do!
User avatar
Conner299
Addict

Posts: 706
Joined: Mon Oct 29, 2012 8:47 am
Location: KY, Louisville
Name: Ed
Vehicle Year: 2005
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Trail Ready

by dvanbramer88 » Fri Mar 01, 2013 11:47 pm

Wahugg wrote: the needle bearings was just a pile of rust and grit.


That was your squeal. Now go replace the other one! :happy whip:
Chevy Power!
Long live the Republic
"Violence is not always evil. The judicious use of violence and those willing to use it without hesitation is often all that stands between wolves and sheep."

Build Thread
User avatar
dvanbramer88
Lifer

Posts: 2283
Joined: Tue Jul 05, 2011 3:12 pm
Location: PA, Bristol
Name: Dave
Vehicle Year: 2002
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Trail Ready

by djthumper » Fri Mar 01, 2013 11:49 pm

Conner299 wrote:See.. If there was a "like" button, I wouldn't have to go through all this B.S., of making a wasteful post.


If there was a "like" button it would be just like on facebook...misused all to hell. :hijack:

Back to our regularly scheduled posting... :cheers:
User avatar
djthumper
Moderator

Posts: 2702
Joined: Wed Mar 24, 2010 6:04 pm
Location: NV, Las Vegas
Name: Larry
Vehicle Year: 2006
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Offroad Rated

by Conner299 » Fri Mar 01, 2013 11:58 pm

djthumper wrote:
Conner299 wrote:See.. If there was a "like" button, I wouldn't have to go through all this B.S., of making a wasteful post.


If there was a "like" button it would be just like on facebook...misused all to hell. :hijack:

Back to our regularly scheduled posting... :cheers:



I disagree with it being exactly like Facebook... 1. Because of our attitude. We are not a "Society" to give out "Due", where "Due" is not deserved. 2. Of course it would be for members only. 3. If anyone ever abused it(Newbs), they would be hazed unmercifully, until they cried, sold their 360(not their X-Box), and walked away from life... Now, Carry on...
I DON'T care what my GMT360 was designed to do, I care about what it can do!
User avatar
Conner299
Addict

Posts: 706
Joined: Mon Oct 29, 2012 8:47 am
Location: KY, Louisville
Name: Ed
Vehicle Year: 2005
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Trail Ready

by dvanbramer88 » Sat Mar 02, 2013 12:04 am

Conner299 wrote:
If anyone ever abused it(Newbs), they would be hazed unmercifully, until they cried, sold their 360(not their X-Box), and walked away from life...



Chevy Power!
Long live the Republic
"Violence is not always evil. The judicious use of violence and those willing to use it without hesitation is often all that stands between wolves and sheep."

Build Thread
User avatar
dvanbramer88
Lifer

Posts: 2283
Joined: Tue Jul 05, 2011 3:12 pm
Location: PA, Bristol
Name: Dave
Vehicle Year: 2002
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Trail Ready

by Conner299 » Sat Mar 02, 2013 12:05 am

dvanbramer88 wrote:
Conner299 wrote:
If anyone ever abused it(Newbs), they would be hazed unmercifully, until they cried, sold their 360(not their X-Box), and walked away from life...





Again... Wish I had a like button...
I DON'T care what my GMT360 was designed to do, I care about what it can do!
User avatar
Conner299
Addict

Posts: 706
Joined: Mon Oct 29, 2012 8:47 am
Location: KY, Louisville
Name: Ed
Vehicle Year: 2005
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Trail Ready

by djthumper » Sat Mar 02, 2013 12:16 am

Conner299 wrote:I disagree with it being exactly like Facebook... 1. Because of our attitude. We are not a "Society" to give out "Due", where "Due" is not deserved. 2. Of course it would be for members only. 3. If anyone ever abused it(Newbs), they would be hazed unmercifully, until they cried, sold their 360(not their X-Box), and walked away from life... Now, Carry on...

Since Newb is a relative term... And hazing is in effect for newbs making newb mistakes such as misuse of a "like" button or not using the "edit" button to fix a post or even add to a post? Like posting a question and then followed by another post by the same newb?

I don't think you are really going to win the argument newbie... :poke:
User avatar
djthumper
Moderator

Posts: 2702
Joined: Wed Mar 24, 2010 6:04 pm
Location: NV, Las Vegas
Name: Larry
Vehicle Year: 2006
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Offroad Rated

by Conner299 » Sat Mar 02, 2013 12:42 am

I absolutely recognize the fact that I'm a newb... But, I'm at least a newb who has respect for the culture. BTW... Can I fit 34's without spacers? :finger: Any help would be appreciated...
I DON'T care what my GMT360 was designed to do, I care about what it can do!
User avatar
Conner299
Addict

Posts: 706
Joined: Mon Oct 29, 2012 8:47 am
Location: KY, Louisville
Name: Ed
Vehicle Year: 2005
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Trail Ready

by Opeth » Sat Mar 02, 2013 12:56 am

Did you do both u joints? Did you get the clips fully seated? Old straps could be improperly stretched, new ones might also help seat the joints. Rotate 180 degrees if vibration is still there... If that didn't help are the balance weights still in place?

If all that fails, bring it to a drive shaft shop to check balance and trueness. 1&2 should resolve the issue if y
User avatar
Opeth
Addict

Posts: 846
Joined: Tue Oct 05, 2010 4:46 pm
Location: NY, Solvay
Name: Cody
Vehicle Year: 2006
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD
Rank: Trail Ready
