Rear BDS spacers with Z71 springs and additional spacers

BDS, ReadyLift, Smaxx... You name it, we know about it here.

by Karo » Sun Mar 03, 2013 10:12 am

Are there any disadvanteges by using a additional spacer under the Z71 springs when having a BDS spacer already installed on top?

When changing the rear axle I m thinking of putting these spacers in with the airlift 1000 bags by keeping the bds spacer on top. My Z 71 already sag a little bit.
Any suggestions?

Karsten
User avatar
Karo
Trail-Blazer

Posts: 342
Joined: Fri Sep 11, 2009 3:02 am
Location: Berlin Germany 52°30'35.16"N, 13°15'31.99"E
Name: Karsten
Vehicle Year: 2002
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD w/ G80
Rank: Trail Ready

by The Roadie » Sun Mar 03, 2013 2:28 pm

That's what I have. BDS on top. Another spacer on the bottom. Z71 plus Airlift1000 bags. I have a replacement $30 set of Z71 springs ready to go in soon.

I see no downside to lift. Better to have more in the rear in case you get hung up on a rock under your frame. As you go forward (if you can) the rock tends to get unjammed. If you are higher inthe front, you have to BACK UP to get out of trouble, and that's not always easy if your winch is on the front and you have nobody behind you to give you a tug. Then you have to relocate the winch (if it's on a multimount) or set up some rigging with your snatch block, etc.
User avatar
The Roadie
Founder

Posts: 5011
Joined: Mon Sep 07, 2009 11:29 pm
Location: OR, Portland area
Name: Bill Carton
Vehicle Year: 2004
Vehicle: GMC Envoy
DriveTrain: 4WD w/ G80
Rank: Expedition Guide

by Karo » Sun Mar 03, 2013 3:08 pm

The Roadie wrote:That's what I have. BDS on top. Another spacer on the bottom. Z71 plus Airlift1000 bags. I have a replacement $30 set of Z71 springs ready to go in soon.

I see no downside to lift. Better to have more in the rear in case you get hung up on a rock under your frame. As you go forward (if you can) the rock tends to get unjammed. If you are higher inthe front, you have to BACK UP to get out of trouble, and that's not always easy if your winch is on the front and you have nobody behind you to give you a tug. Then you have to relocate the winch (if it's on a multimount) or set up some rigging with your snatch block, etc.


Thank´s Bill, it is good to know that it is a "proven setup"!
I wan´t more lift in the back especially for the rear gas tank. Getting a spare setup of coils is on my list. I plan on making a trip to middle sweden in the end of april and still have to do a lot of work on the Trailblazer. I will carry a lot of things in the back of the Trailblazer on that trip. Your tip on having the rear higher than the front is essential in case of a hung up rock under the frame. I have no practical experience with that situation, so it is a good point to know!
User avatar
Karo
Trail-Blazer

Posts: 342
Joined: Fri Sep 11, 2009 3:02 am
Location: Berlin Germany 52°30'35.16"N, 13°15'31.99"E
Name: Karsten
Vehicle Year: 2002
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD w/ G80
Rank: Trail Ready

by The Roadie » Sun Mar 03, 2013 3:47 pm

Karo wrote:...I have no practical experience with that situation, ...
Well, then.... In case a parking lot curb at the mall catches on your frame. :finger:
Attachments
User avatar
The Roadie
Founder

Posts: 5011
Joined: Mon Sep 07, 2009 11:29 pm
Location: OR, Portland area
Name: Bill Carton
Vehicle Year: 2004
Vehicle: GMC Envoy
DriveTrain: 4WD w/ G80
Rank: Expedition Guide

by Karo » Sun Mar 03, 2013 5:02 pm

I know getting a picture from you for telling the truth.. :finger:
User avatar
Karo
Trail-Blazer

Posts: 342
Joined: Fri Sep 11, 2009 3:02 am
Location: Berlin Germany 52°30'35.16"N, 13°15'31.99"E
Name: Karsten
Vehicle Year: 2002
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD w/ G80
Rank: Trail Ready

by The Roadie » Sun Mar 03, 2013 6:39 pm

The famous US writer, Samuel Clemens (Mark Twain) said once: "Always tell the truth.....there's so much less to remember that way." :excited:
User avatar
The Roadie
Founder

Posts: 5011
Joined: Mon Sep 07, 2009 11:29 pm
Location: OR, Portland area
Name: Bill Carton
Vehicle Year: 2004
Vehicle: GMC Envoy
DriveTrain: 4WD w/ G80
Rank: Expedition Guide

by HARDTRAILZ » Sun Mar 03, 2013 10:19 pm

I ran that basic setup for a good while, but am glad i went to the Skyjacker springs. Just seems to ride better and its just the spring with no spacer but same lift.
I hate to advocate weird chemicals, alcohol, violence or insanity to anyone...but
they've always worked for me.
User avatar
HARDTRAILZ
Moderator

Posts: 6342
Joined: Sat Sep 12, 2009 1:49 am
Location: IN, Batesville
Name: Kyle
Vehicle Year: 2006
Vehicle: Chevrolet TrailBlazer
DriveTrain: 4WD w/ Aftermarket Locker
